Tenable.sc

Tenable.sc is a vulnerability management and security configuration tool that scans, consolidates, and evaluates vulnerability data from your entire network. You can bring asset and security data from Tenable.sc into Brinqa to calculate risk scores, construct a unified view of your attack surface, and strengthen your cybersecurity posture.

This document details the information you must provide for the connector to authenticate with Tenable.sc and how to obtain that information from Tenable. See create a data integration for step-by-step instructions on setting up the integration.

info

The Tenable.sc connector supports Tenable Security Center versions 5 and above, with testing currently ongoing for version 6.4. For additional information, see Tenable Security Center downloads and release notes.

Required connection settings

When setting up a data integration, select Tenable.sc from the Connector drop-down. If you cannot find the connector in the drop-down, make sure that you have installed it first. You must provide the following information to authenticate Tenable.sc with Brinqa:

• Server URL: The Tenable.sc Server URL.

• Access key and Secret key: The access key and secret key associated with the Tenable.sc account, which must have permissions to log in to the API server and return data.

Generate Tenable.sc access key and secret key

For the Tenable.sc connector to use the Tenable.sc API, you must provide the access key and secret key from Tenable.sc.

Before you can generate a new access key and secret key, you must enable API key authentication. To do so, follow these steps:

1. Log in to your organization's Tenable.sc account as an administrator.

2. Navigate to System > Configuration, and then click Security.

3. In Authentication Settings, click Allow API Keys.

4. Click Submit.

To generate new API keys for authentication, follow these steps:

1. Log in to your organization's Tenable.sc account as an administrator.

2. Navigate to Users > Users.

3. Right-click the user for which you want to generate new API keys.

4. Click API Keys > Generate API Key.

5. Review the confirmation and click Generate.

   Your new Tenable.sc access key and secret key display in the window. Copy the access key and secret key to a safe and secure location.

note

If you do not have the permissions to create Tenable.sc access and secret keys, contact your Tenable.sc administrator. For additional information, see Tenable.sc documentation.

Required ports

To ensure proper communication between your on-premise Brinqa Agent servers and the Tenable.sc on-prem server, the following port must be opened:

• Port 443 (HTTPS): This port is used for secure communication between the Brinqa Agent and Tenable.sc. Ensure that this port is open for outbound and inbound traffic on any firewall protecting the Tenable.sc server.

The Tenable.sc connector is set up using a URL provided by the Tenable administrator. The URL is typically in the format https://host..., where the https:// part indicates that the communication is over HTTPS, using port 443. However, the specific port can be configured differently based on your network and security setup. For instance, if the URL is in the format http://host:<PORT>, then the specified port will be used. The exact port and route that need to be open and accessible are determined by the Tenable.sc administrator and network team. The Brinqa connector or Brinqa Agent does not have any specific port requirement; it depends on how Tenable.sc is configured.

Additional settings

The Tenable.sc connector contains additional options for specific configuration:

• Set page size: The maximum number of records to get per API request. The default setting is 1000. It is not recommended to go over 1000.

• Parallel requests: The maximum number of parallel API requests. The default setting is 8.

• Maximum retries: The maximum number of times that the integration attempts to connect to the Tenable.sc API before giving up and reporting a failure. The default setting is 10.

• Skip certificate verification: Select this option to allow for untrusted certificates.

Types of data to retrieve

The Tenable.sc connector can retrieve the following types of data from the Tenable.sc API:

Table 1: Data retrieved from Tenable.sc

Connector Object	Required	Maps to Data Model
Host	Yes	Host
Vulnerability	Yes	Vulnerability
Vulnerability Definition	Yes	Vulnerability Definition

info

Tenable.sc refers to Vulnerability Definitions as Plugins.

For detailed steps on how to view the data retrieved from Tenable.sc in the Brinqa Platform, see How to view your data.

Attribute mappings

Click the tabs below to view the mappings between the source and the Brinqa data model attributes.

Host

Table 2: Host attribute mappings

Source Field Name	Maps to Attribute
host.createdTime	sourceCreatedDate
host.dns, record.dnsName	publicDnsName, privateDnsName
host.dns	name
host.firstSeen	firstSeen
host.ipAddress	name
host.ipAddress, record.ip	ipAddresses, publicIpAddresses, privateIpAddresses
host.lastSeen	lastSeen
host.macAddress, record.macAddress	macAddresses
host.modifiedTime	sourceLastModified
host.name	name
host.netBios	name
host.tenableUUID	Local variable
record.dnsName	name
record.identifier	name
record.ip	name
record.netbiosName	name
record.serial	name
repository.id (host)	Local variable
repository.name (host)	Local variable
STATUS	status
uid	uid
vuln.asset.fqdn	privateDnsName, publicDnsName
vuln.asset.hostname	hostnames
vuln.asset.ipv4	ipAddresses
vuln.asset.mac_address	macAddresses
vuln.asset.uuid	targets
vuln.first_found	firstFound
vuln.last_fixed	Local variable
vuln.last_found	lastFound
vuln.plugin.id	type
vuln.port.port	port
vuln.port.protocol	protocol
vuln.output	results
vuln.severity_id	severity, sourceSeverity
vuln.state	sourceStatus, statusCategory, status

Vulnerability

Table 3: Vulnerability attribute mappings

Source Field Name	Maps to Attribute
repository.id (vuln)	Local variable
repository.name (vuln)	Local variable
record.sourceType	status, sourceStatus, statusCategory
uniqueAssetId	uid, targets
vuln.acceptRisk	Local variable
vuln.dnsName	publicDnsName, privateDnsName
vuln.firstSeen	firstFound
vuln.identifier	uid, targets
vuln.ip	ipAddresses
vuln.lastMitigated	lastFixed
vuln.lastSeen	lastFound
vuln.macAddress	macAddresses
vuln.netbiosName	hostname
vuln.pluginId	uid, type
vuln.pluginText	results
vuln.port	uid, port
vuln.protocol	uid, protocol
vuln.recastRisk	Local variable
vuln.serial	uid, targets
vuln.severity	severity, sourceSeverity

Vulnerability Definition

Table 4: Vulnerability Definition attribute mappings

Source Field Name	Maps to Attribute
age_of_vuln	Local variable
cvssV3_impactScore	Local variable
exploit_code_maturity	Local variable
PATCH_AVAILABLE	patchAvailable
plugin.baseScore	cvssV2BaseScore
plugin.checkType	Local variable
plugin.cpe	affected
plugin.cvssVector	cvssV2Vector
plugin.cvssV3BaseScore	cvssV3BaseScore
plugin.cvssV3TemporalScore	cvssV3TemporalScore
plugin.cvssV3Vector	cvssV3Vector
plugin.description	description
plugin.exploitAvailable	Local variable
plugin.exploitEase	Local variable
plugin.exploitFrameworks	exploits
plugin.family	categories
plugin.id	uid
plugin.modifiedTime	sourceLastModified
plugin.name	name
plugin.patchPubDate	Local variable
plugin.pluginModDate	sourceLastModified
plugin.pluginPubDate	publishedDate
plugin.riskFactor	severity, sourceSeverity, severityScore
plugin.solution	recommendation
plugin.synopsis	summary
plugin.temporalScore	cvssV2TemporalScore
plugin.type	Local variable
plugin.vprScore	Local variable
plugin.xrefs	cveIds, cveRecords, references
plugin.seeAlso	Local variable
predicted_impactScore	Local variable
product_coverage	Local variable
threat_intensity_last_28	Local variable
threat_model_type	Local variable
threat_model_version	Local variable
threat_recency	Local variable
threat_sources_last_28	Local variable

info

Local variable indicates that the field is processed within a specific context, such as a particular workflow or calculation. Unlike other attributes, local variables aren't mapped to the unified data models. They only exist on the source data model.

Operation options

The Tenable.sc connector supports the following operation options. See connector operation options for information about how to apply them.

Table 5: Tenable.sc connector operation options

Connector Object	Option	All Possible Values	Description	Example
Host	asset	Any number identifying the hosts in your network.	Retrieves the host that is associated with the specified asset ID.	Key: asset Value: 123456789. This key and value combination only retrieves the host with asset ID 123456789.
	ip	Any valid IP addresses or DNS names in your network.	A comma-separated list of valid IP addresses or DNS names in your network.	Key: ip Value: 192.168.1.1. This key and value combination only retrieves the host whose IP address is 192.168.1.1.
	per_repo_distinct_asset_uuid	true or false	Indicate whether to create a unique identifier when the same asset is found in multiple repositories.	Key: per_repo_distinct_asset_uuid Value: true. This key and value combination creates a unique identifier when the same asset is found in multiple repositories.
Vulnerability	asset	Any number identifying the hosts in your network.	Retrieves the vulnerabilities that are associated with the specified asset ID.	Key: asset Value: 123456789. This key and value combination only retrieves the vulnerabilities that are associated with asset ID 123456789.
	baseCVSSScore or cvssV2BaseScore	Any numeric value ranges from from 0.1-10.0.	Retrieves all vulnerabilities with the specified Common Vulnerability Score System (CVSS) V2 score or range of CVSS V2 scores. Values are separated by a dash -.	Key: baseCVSSScore Value: 8. This key and value combination only retrieves vulnerabilities with a CVSS V2 score of 8.
	cvssV3BaseScore	Any numeric value ranges from 0.1-10.0	Retrieves all vulnerabilities with the specified CVSS V3 score or range of CVSS V3 scores. Values are separated by a dash -.	Key: cvssV3BaseScore Value: 3. This key and value combination only retrieves vulnerabilities with a CVSS V3 score of 3.
	infoPlugins	Any supported Tenable.sc plugin ID number or range of plugin IDs from 0-8388607.	A comma-separated list of plugin IDs. Retrieves additional information about each plugin associated with the vulnerabilities identified in your network, such as the plugin's name, description, severity, and other details.	Key: infoPlugins Value: 123456,789012. This key and value combination only retrieves detailed information about the plugins with IDs 123456 and 789012.
	ip	Any valid IP addresses or DNS names in your network.	A comma-separated list of valid IP addresses or DNS names in your network.	Key: ip Value: 192.168.1.1. This key and value combination only retrieves the vulnerabilities associated with the IP address 192.168.1.1.
	mitigated	never or previously	Retrieves vulnerabilities by their mitigation status.	Key: mitigated Value: never. This key and value combination only retrieves vulnerabilities that have not been mitigated.
	per_repo_distinct_asset_uuid	true or false	Indicate whether to create a unique identifier when the same asset is found in multiple repositories.	Key: per_repo_distinct_asset_uuid Value: true. This key and value combination creates a unique identifier when the same asset is found in multiple repositories.
	plugin or pluginID	Any supported Tenable.sc plugin ID number or range of plugin IDs from 0-8388607.	Retrieves vulnerabilities that are related to the specified plugin ID or range of plugin IDs. Plugin IDs are separated by a dash -.	Key: pluginID Value: 123456. This key and value combination only retrieves vulnerabilities associated with plugin ID 123456.
	pluginType	active, compliance, lce, or passive	Retrieves vulnerabilities that are related to the specified plugin types.	Key: pluginType Value: active, compliance. This key and value combination only retrieves active and compliant plugins that are used to identify vulnerabilities.
	repository	Any vulnerability repository.	Retrieves only vulnerabilities from the specified repository.	Key: repository Value: repo2. This key and value combination only retrieves vulnerabilities from the repo2 repository.
	severity	Any number from 0-4.	Retrieves vulnerabilities based on their specified severity level. 0 = Informational, 1 = Low, 2 = Medium, 3 = High, and 4 = Critical.	Key: severity Value: 4: This key and value combination only retrieves vulnerabilities with a severity level of 4, or critical vulnerabilities.
	vprScore	Any numeric value from 0.1-10.0.	Retrieve all vulnerabilities with a Vulnerability Priority Rating (VPR) score of the specified value or higher.	Key: vpr_score Value: 7. This key and value combination retrieves all vulnerabilities with a VPR score of 7 or higher.

note

The option keys and values are case-sensitive as they are shown in this documentation.

APIs

The Tenable.sc connector uses the Tenable.sc REST API. Specifically, it uses the following API endpoints:

Table 6: Tenable.sc REST API Endpoints

Connector Object	API Endpoint
Host	POST /rest/hosts/search
Vulnerability	POST /rest/analysis
	GET /rest/status
Vulnerability Definition	GET /rest/plugin

Changelog

The Tenable.sc connector has undergone the following changes:

3.1.26

• No change.

3.1.25

• No change.

3.1.24

• No change.

3.1.23

• No change.

3.1.22

• No change.

3.1.21

• No change.

3.1.20

• Changed the EXPLOIT_AVAILABILITY attribute on the Vulnerability Definition object from a String to a Boolean.

3.1.18

• Added a VULNERABILITY_PUBLISHED_DATE attribute to the Vulnerability Definition object.

3.1.16

• Addressed precision issues by changing the data type for CVSS scores from Float to Double.

3.1.15

• Changed the SOURCE_SEVERITY attribute to a String type.

• Added a SOURCE_SEVERITY_SCORE attribute in the Vulnerability and Vulnerability Definition object.

3.1.14

• Normalized the HOSTNAME attribute in the Host object.

3.1.13

• Added a new operation option, per_repo_distinct_asset_uuid, to indicate whether to create a unique identifier when the same asset is found in multiple repositories.

3.1.12

• Added a new setting to configure maximum retries.

3.1.11

• Added a SOURCE_STATUS attribute in the Vulnerability object to store the source finding statuses.

• Added a method to normalize the source finding statuses.

3.1.10

• Added operation options to retrieve vulnerabilities based on both severity and plugins.

3.1.9

• Avoided retrieving nanoseconds by changing the data type of date attributes from Long to Instant.

3.1.4

• Set the vulnerability status to 'Risk accepted' if the acceptRisk attribute on the source data is marked as 'true'.

3.1.2

• Added a check for null or empty dates.

3.0.5

• Added a PATCH_PUBLICATION_DATE attribute in the Vulnerability Definition object.

3.0.0

• Initial Integration+ release.
