Tenable.io

Tenable.io is a cloud-based vulnerability management tool that scans hosts in your network and generates vulnerabilities against those hosts. You can bring asset and security data from Tenable.io into Brinqa to enhance your vulnerability management capabilities, gain insights into the relationship between the vulnerabilities and your assets, construct a unified view of your attack surface, and strengthen your cybersecurity posture.

This document details the information you must provide for the connector to authenticate with Tenable.io and how to obtain that information from Tenable. See create a data integration for step-by-step instructions on setting up the integration.

Required connection settings

When setting up a data integration, select Tenable.io from the Connector drop-down. If you cannot find the connector in the drop-down, make sure that you have installed it first. You must provide the following information to authenticate Tenable.io with Brinqa:

• API URL: The Tenable.io API URL. The default URL is https://cloud.tenable.com.

• Access key and Secret key: The access key and secret key associated with the Tenable.io account, which must have permissions to log in to the API server and return data.

Generate Tenable.io access key and secret key

In order for the Tenable.io connector to successfully retrieve data from the Tenable.io API, the access key and secret key must be tied to a Basic user role with Can View permissions. For additional information, see Tenable.io documentation on permissions.

For the Tenable.io connector to use the Tenable.io API, you must provide an access key and secret key. Tenable.io does not allow retrieving the access key and secret key for an existing user, therefore, you must generate new keys instead.

To generate new access keys, follow these steps:

1. Log in to your Tenable.io account.

2. Click the Menu button on the upper-left corner of the page. A navigation pane appears.

3. Click Settings, and then click My Account.

4. Click the User Account button on the upper-right corner of the page, and then click the API Keys tab.

5. Click Generate. The Generate API Keys window appears.

6. Review the warning on the page and click Generate.

   Your new Tenable.io access key and secret key display. Copy the access key and secret key to a safe and secure location.

To generate a new access key and secret key for another user as an administrator, follow these steps:

1. Log in to your Tenable.io account as an administrator.

2. Click the Menu button on the upper-left corner of the page. A navigation pane appears.

3. Click Settings, and then click Access Control.

4. Click the name of the user for which you want to generate an access key and secret key. The Edit User page appears.

5. In the API Keys section, click Generate API Keys.

6. Review the warning on the page and click Replace & Generate.

   The new Tenable.io access key and secret key display. Copy the access key and secret key to a safe and secure location.

note

If you do not have permissions to create Tenable.io access and secret keys, contact your Tenable.io administrator. For additional information, see Tenable.io documentation on API keys.

Additional settings

The Tenable.io connector contains additional options for specific configuration:

• Page size: The maximum number of records to get per API request. The default setting is 1000. It is not recommended to go over 1000.

• Parallel requests: The maximum number of parallel API requests. The default setting is 8.

• Maximum retries: The maximum number of times that the integration attempts to connect to the Tenable.io API before giving up and reporting a failure. The default setting is 10.

Types of data to retrieve

The Tenable.io connector can retrieve the following types of data from the Tenable.io API:

Table 1: Data retrieved from Tenable.io

Connector Object	Required	Maps to Data Model
Assessment	No	Not mapped
Host	Yes	Host
Violation	Yes	Violation
Violation Definition	Yes	Violation Definition
Vulnerability	Yes	Vulnerability
Vulnerability Definition	Yes	Vulnerability Definition

info

For detailed steps on how to view the data retrieved from Tenable.io in the Brinqa Platform, see How to view your data.

Tenable compliance audit results can be found under Violations.

Attribute mappings

Expand the sections below to view the mappings between the source and the Brinqa data model attributes.

Host

Table 2: Host attribute mappings

Source Field Name	Maps to Attribute
asset.agent_names	Local variable
asset.agent_uuid	Local variable
asset.aws_availability_zone	Local variable
asset.aws_ec2_instance_ami_id	Local variable
asset.aws_ec2_instance_group_name	Local variable
asset.aws_ec2_instance_id	Local variable
asset.aws_ec2_instance_state_name	Local variable
asset.aws_ec2_instance_type	Local variable
asset.aws_ec2_name	Local variable
asset.aws_ec2_product_code	Local variable
asset.aws_owner_id	Local variable
asset.aws_region	Local variable
asset.aws_subnet_id	Local variable
asset.aws_vpc_id	Local variable
asset.azure_resource_id	Local variable
asset.azure_vm_id	Local variable
asset.created_at	sourceCreatedDate
asset.deleted_at	Local variable
asset.deleted_by	Local variable
asset.first_scan_time	Local variable
asset.first_seen	firstSeen
asset.fqdns	dnsNames
asset.gcp_instance_id	Local variable
asset.gcp_project_id	Local variable
asset.gcp_zone	Local variable
asset.has_agent	Local variable
asset.hostnames	hostnames
asset.id	uid
asset.ipv4s	privateIpAddresses
asset.ipv6s	ipAddresses
asset.last_authenticated_scan_date	Local variable
asset.last_scan_id	Local variable
asset.last_scan_time	lastScanned
asset.last_schedule_id	Local variable
asset.last_seen	lastSeen
asset.mac_addresses	macAddresses
asset.mcafee_epo_agent_guid	Local variable
asset.mcafee_epo_guid	Local variable
asset.network_id	Local variable
asset.operating_systems	os
asset.public_ipv4s	publicIpAddresses
asset.servicenow_sysid	Local variable
asset.sources	Local variable
asset.tags	tags
asset.terminated_at	Local variable
asset.terminated_at/asset.delete_at	status
asset.terminated_by	Local variable
categories	categories
description	description
instanceId	cloudInstanceId
LAST_LICENSED_SCAN	Local variable
lastScan.name	Local variable

info

Local variable indicates that the field is processed within a specific context, such as a particular workflow or calculation. Unlike other attributes, local variables aren't mapped to the unified data models. They only exist on the source data model.

Violation

Table 3: Violation attribute mappings

Source Field Name	Maps to Attribute
ACTUAL_VALUE	Local variable
AUDIT_FILE	Local variable
CHECK_ERROR	Local variable
CHECK_ID	Local variable
CHECK_INFO	Local variable
CHECK_NAME	Local variable
DB_TYPE	Local variable
EXPECTED_VALUE	Local variable
FIRST_SEEN	firstSeen
HOST_ID	targets, Local variable
LAST_SEEN	lastSeen
PLUGIN_ID	targets, Local variable
PROFILE_NAME	Local variable
REFERENCES	references
SEE_ALSO	Local variable
SOLUTION	recommendation
STATUS	status, sourceStatus, statusCategory
SYS_ID	uid

info

Local variable indicates that the field is processed within a specific context, such as a particular workflow or calculation. Unlike other attributes, local variables aren't mapped to the unified data models. They only exist on the source data model.

Violation Definition

Table 4: Violation Definition attribute mappings

Source Field Name	Maps to Attribute
AFFECTED	affected
CATEGORIES	categories
CVE_IDS	cveIds
CVE_RECORDS	cveRecords
CVSS_IMPACT_SCORE_PREDICTED	Local variable
CVSS_V2_VECTOR	Use CVSS calculator
CVSS_V3_IMPACT_SCORE	Local variable
CVSS_V3_VECTOR	Use CVSS calculator
DESCRIPTION	description
EXPLOIT_AVAILABLE	Local variable
EXPLOIT_CODE_MATURITY	Local variable
EXPLOIT_EASE	Local variable
EXPLOITS	exploits
NAME	name
PATCH_AVAILABLE	patchAvailable
PATCH_PUBLICATION_DATE	Local variable
PLUGIN_TYPE	Local variable
PRODUCT_COVERAGE	Local variable
PUBLISHED_DATE	publishedDate
RECOMMENDATION	recommendation
REFERENCES	references
SEE_ALSO	Local variable
SEVERITY	severity, sourceSeverity, severityScore
SEVERITY_SCORE	severityScore
SOURCE_LAST_MODIFIED	sourceLastModified
SUMMARY	summary
THREAT_INTENSITY	Local variable
THREAT_RECENCY	Local variable
THREAT_SOURCES	Local variable
UID	uid
VPR_SCORE	Local variable

info

Local variable indicates that the field is processed within a specific context, such as a particular workflow or calculation. Unlike other attributes, local variables aren't mapped to the unified data models. They only exist on the source data model.

Use CVSS calculator indicates that the CVSS (Common Vulnerability Scoring System) vectors and scores aren't directly mapped to a specific attribute on the UDM. Instead, a specialized library calculates the CVSS scores from the provided CVSS vector strings.

Vulnerability

Table 5: Vulnerability attribute mappings

Source Field Name	Maps to Attribute
uid	uid
vuln.asset.agent_uuid	Local variable
vuln.asset.fqdn	privateDnsName, publicDnsName
vuln.asset.hostname	hostnames
vuln.asset.ipv4	ipAddresses
vuln.asset.mac_address	macAddresses
vuln.asset.uuid	targets
vuln.first_found	firstFound
vuln.last_fixed	Local variable
vuln.last_found	lastFound
vuln.output	results
vuln.plugin.id	type
vuln.port.port	port
vuln.port.protocol	protocol
vuln.scan.schedule_uuid	Local variable
vuln.scan.uuid	Local variable
vuln.severity_id	severity, sourceSeverity
vuln.severity_modification_type	Local variable
vuln.state	status, statusCategory

info

Local variable indicates that the field is processed within a specific context, such as a particular workflow or calculation. Unlike other attributes, local variables aren't mapped to the unified data models. They only exist on the source data model.

Vulnerability Definition

Table 6: Vulnerability Definition attribute mappings

Source Field Name	Maps to Attribute
cvss_vector	Use CVSS calculator
drivers.cvss3_impact_score	Local variable
drivers.cvss_impact_score_predicted	Local variable
drivers.exploit_code_maturity	Local variable
drivers.exploitability_ease	Local variable
drivers.product_coverage	Local variable
drivers.threat_intensity_last28	Local variable
drivers.threat_recency	Local variable
drivers.threat_sources_last28	Local variable
family	categories
plugin.attributes.cpe	affected
plugin.attributes.description	description
plugin.attributes.exploit_available	Local variable
plugin.attributes.exploit_framework_	exploits
plugin.attributes.exploitability_ease	Local variable
plugin.attributes.has_patch	patchAvailable
plugin.attributes.patch_publication_date	patchPublishedDate
plugin.attributes.plugin_modification_date	sourceLastModified
plugin.attributes.plugin_type	Local variable
plugin.attributes.risk_factor	sourceSeverity, severity, severityScore
plugin.attributes.see_also	Local variable
plugin.attributes.solution	recommendation
plugin.attributes.synopsis	summary
plugin.attributes.vpr	Local variable
plugin.attributes.vuln_publication-date	publishedDate
plugin.attributes.xref	cveIds, cveRecords
plugin,attributes.xref	cveIds, cveRecords
PLUGIN_PREFIX + plugin.id	uid
plugin.name	name

info

Local variable indicates that the field is processed within a specific context, such as a particular workflow or calculation. Unlike other attributes, local variables aren't mapped to the unified data models. They only exist on the source data model.

Use CVSS calculator indicates that the CVSS (Common Vulnerability Scoring System) vectors and scores aren't directly mapped to a specific attribute on the UDM. Instead, a specialized library calculates the CVSS scores from the provided CVSS vector strings.

Operation options

The Tenable.io connector supports the following operation options. Expand the sections below to view the operation options per supported connector object. See connector operation options for information about how to apply them.

Host operation options

Table 7: Host operation options

Connector Object	Option	All Possible Values	Description	Example
Host	chunk_size	Any number ranges from 100-10000	Specifies the number of hosts that are exported in a batch. Tenable recommends not exceeding 5000.	Key: chunk_size Value: 100. This key and value combination only retrieves 100 hosts at a time. Once 100 hosts are exported, the next group of 100 hosts exports.
	has_plugin_results	true or false	Filters hosts by whether or not they have plugin results associated with it.	Key: has_plugin_results Value: true. This key and value combination only retrieves hosts that have plugin results.
	is_deleted	true or false	Filters hosts by whether or not they have been deleted.	Key: is_deleted Value: false. This key and value combination only retrieves hosts that exist and are active.
	is_licensed	true or false	Filters hosts by whether or not they are included in the asset count for Tenable.io.	Key: is_licensed Value: true. This key and value combination only retrieves hosts that are licensed and authorized to run.
	is_terminated	true or false	Filters hosts by whether or not they have been terminated.	Key: is_terminated Value: true. This key and value combination only retrieves hosts that have been terminated.
	last_assessed	Any date value in the Unix timestamp format	Returns all hosts with a last assessed time later than the specified date.	Key: last_assessed Value: 1593000000. This key and value combination only retrieves hosts that have been assessed since (UTC) July 12th, 2020 at 21:40:00.
	servicenow_sysid	true or false	Filters hosts by whether or not they have a ServiceNow Sys ID.	Key: servicenow_sysid Value: true. This key and value combination only retrieves hosts that have a ServiceNow Sys ID.
	sources	AWS, NESSUS_AGENT, PVS, NESSUS_SCAN, or WAS	A comma-separated list of sources that filter hosts by whether or not they are discovered by the specified source.	Key: sources Value: NESSUS_SCAN, AWS. This key and value combination only retrieves hosts that are from AWS or discovered in a Nessus scan.
	tag.<category>	Any Tenable.io tag category name	Filters hosts with the specified tag category. For additional information on tags, see Tenable.io documentation	Key: tag.<category> Value: Test2. This key and value combination only retrieves hosts with the Test2 tag category.

note

The option keys and values are case-sensitive as they are shown in this documentation.

Violation operation options

Table 8: Violation operation options

Connector Object	Option	All Possible Values	Description	Example
Violation	chunkTimeout	Any time value in seconds	Specifies the maximum amount of time in seconds to wait for a chunk of violation data to be retrieved.	Key: chunkTimeout Value: 60. This key and value combination sets the timeout for chunk retrieval to 60 seconds.
	exportTimeout	Any time value in seconds	Specifies the maximum amount of time in seconds to wait for the entire violation data export process to complete.	Key: exportTimeout Value: 300. This key and value combination sets the export process timeout to 5 minutes.
	initialTimeout	Any time value in seconds	Defines the initial waiting time in seconds before the export process begins.	Key: initialTimeout Value: 30. This key and value combination sets an initial delay of 30 seconds before starting the export.
	last_seen	Any date value in the Unix timestamp format	Returns all violations with a last seen time later than the specified date.	Key: last_seen Value: 1609459200. This key and value combination only retrieves violations seen after January 1, 2021.
	num_findings	Any number ranges from 50-5000	Specifies the number of findings used to chunk the vulnerabilities.	Key: num_findings Value: 1000. This key and value combination retrieves violations for 1000 findings at a time. Once the violations for the 1000 findings are exported, the violations for the next group of 1000 findings export.
	pollInterval	Any time value in seconds	Sets the interval time in seconds between polling attempts for new data.	Key: pollInterval Value: 10. This key and value combination sets the polling interval for new violations to 10 seconds.

note

The option keys and values are case-sensitive as they are shown in this documentation.

Vulnerability operation options

Table 9: Vulnerability operation options

Connector Object	Option	All Possible Values	Description	Example
Vulnerability	cidr_range	Any range of IP addresses assigned to the hosts in your network	Restricts search for vulnerabilities to the hosts assigned an IP address within the specified CIDR range.	Key: cidr_range Value: 192.168.0.0/24. This key and value combination only retrieves vulnerabilities on the hosts bearing the IP addresses from 192.168.0.1 to 192.168.0.254.
	include_unlicensed	true or false	Filters vulnerabilities by whether or not to include unlicensed hosts.	Key: include_unlicensed Value: true. This key and value combination retrieves vulnerabilities from both licensed and unlicensed hosts.
	num_assets	Any number ranges from 50-5000	Specifies the number of hosts used to chunk the vulnerabilities.	Key: num_assets Value: 100. This key and value combination retrieves vulnerabilities for 100 hosts at a time. Once the vulnerabilities for the 100 hosts are exported, the vulnerabilities for the next group of 100 hosts export.
	plugin_family	Any Tenable.io plugin family string	Filters vulnerabilities by whether or not they are related to the specified plugin family.	Key: plugin_family Value: operating systems. This key and value combination only retrieves vulnerabilities related to the operating systems plugin family.
	plugin_id	Any supported Tenable.io plugin ID number	Filters vulnerabilities by whether or not they are related to the specific plugin ID.	Key: plugin_id Value: 10150. This key and value combination only retrieves vulnerabilities associated with plugin ID 10150.
	plugin_type	Any supported plugin type: remote, local, combined, etc.	Filters vulnerabilities by whether or not they are related to the specified plugin type.	Key: plugin_type Value: mobile. This key and value combination only retrieves vulnerabilities associated with the mobile plugin type.
	severity	low, medium, high, or critical	Returns all vulnerabilities of the specified severity.	Key: severity Value: critical. This key and value combination only retrieves the critical vulnerabilities found in a scan.
	since	Any date value in the Unix timestamp format	Returns all vulnerabilities seen since the specified date value.	Key: since Value: 1593000000. This key and value combination only retrieves vulnerabilities that exist since (UTC) July 12th, 2020 at 21:40:00.
	state or status	fixed, open, or reopened	Returns all vulnerabilities with the specified state or status.	Key: status Value: open. This key and value combination only retrieves open vulnerabilities. You can use state for the key in place of status and it produces the same result.
	tag.<category>	Any Tenable.io tag category name	Returns all vulnerabilities with the specified tag category. For additional information on tags, see Tenable.io documentation	Key: tag.<category> Value: Test2. This key and value combination only retrieves vulnerabilities with the Test2 tag category.
	vpr_score	Any numeric value from 0.1-10.0	Retrieve all vulnerabilities with a Vulnerability Priority Rating (VPR) score of the specified value or higher.	Key: vpr_score Value: 7. This key and value combination retrieves all vulnerabilities with a VPR score of 7 or higher.

note

The option keys and values are case-sensitive as they are shown in this documentation.

APIs

The Tenable.io connector uses the Tenable.io REST API. Specifically, it uses the following endpoints:

Table 10: Tenable.io REST API Endpoints

Connector Object	API Endpoints
Host	POST https://cloud.tenable.com/assets/export
	POST https://cloud.tenable.com/assets/export/{export_uuid}/cancel
	GET https://cloud.tenable.com/assets/export/{export_uuid}/chunks/{chunk_id}
	GET https://cloud.tenable.com/assets/export/{export_uuid}/status
Violation	POST https://cloud.tenable.com/compliance/export
	GET https://cloud.tenable.com/compliance/export/{export_uid}/chunks/{check_id}
	GET https://cloud.tenable.com/plugins/families/{familyId}
Violation Definition	GET https://cloud.tenable.com/plugins/families/
	GET https://cloud.tenable.com/plugins/plugin
Vulnerability	POST https://cloud.tenable.com/vulns/export
	POST https://cloud.tenable.com/vulns/export/{export_uuid}/cancel
	GET https://cloud.tenable.com/vulns/export/{export_uuid}/chunks/{chunk_id}
	GET https://cloud.tenable.com/vulns/export/{export_uuid}/status
Vulnerability Definition	GET https://cloud.tenable.com/plugins/families
	GET https://cloud.tenable.com/plugins/families/{familyId}
	GET https://cloud.tenable.com/plugins/plugin

Changelog

The Tenable.io connector has undergone the following changes:

3.1.19

• Added two connector objects, Violation and Violation Definition.

• Started fetching Tenable Compliance Check results and storing them as violations.

3.1.17

• Changed the data type of 'acr_score' and 'exposure_score' from Integer to Double to align with the API response format.

3.1.16

• Addressed precision issues by changing the data type for CVSS scores from Float to Double.

3.1.15

• Changed the SOURCE_SEVERITY attribute to a String type.

• Added a SOURCE_SEVERITY_SCORE attribute in the Vulnerability and Vulnerability Definition object.

3.1.12

• Added a new setting to configure maximum retries.

3.1.11

• Added a SOURCE_STATUS attribute in the Vulnerability object to store the source finding statuses.

• Added a method to normalize the source finding statuses.

3.1.3

• Started retrieving scans of all statuses.

3.1.2

• Added a check for null or empty dates.

3.1.1

• Started retrieving name, rrules, starttime, and uuid from the Tenable vulnerability management scans.

3.0.11

• Added a SEVERITY_MODIFICATION_TYPE attribute in the Vulnerability object.

3.0.8

• Added some new attributes in the Host object, including AWS_EC2_INSTANCE_ID, AZURE_RESOURCE_ID, and GCP_INSTANCE_ID.

• Used AZURE_VM_ID, if available, as the instance ID of Azure hosts.

3.0.7

• Added 'SSM' as a valid source for hosts.

3.0.6

• Added a LAST_SCAN_NAME attribute in the Host object.

3.0.5

• Added a PATCH_PUBLICATION_DATE attribute in the Vulnerability Definition object.

3.0.3

• Fixed an issue in parsing CVSS v3 vectors.

3.0.0

• Initial Integration+ release.
